Diagnostic Aids
Scan tester should indicate a vehicle speed whenever the drive wheels are turning faster than 3 MPH. Check white wire for proper connections. Ensure wire connector is clean and tight and harness is routed correctly. For intermittent inspection, see INTERMITTENTS in appropriate TESTS W/O CODES article in the ENGINE PERFORMANCE Section.
