Supplemental Restraint System Steering Wheel & Column: Installation

To install the connector, hold the socket insulator(1) and insert it. The cover insulator slides and connector will be locked.

Do not hold the cover insulator(2).

Fig 1: Installing Connector Holding Socket Insulator & Inserting

Courtesy of ISUZU MOTOR CO.
