Supplemental Restraint System Steering Wheel & Column: Installation

To install the connector, hold the socket insulator (1) and insert it. The cover insulator slides and connector will be locked.

Do not hold the cover insulator (2).

Fig 1: Installing Socket Insulator
G02778050
