Lighting System Connector End Views
›
Turn Signal/Multi-Function Switch C4
Turn Signal/Multi-Function Switch C4
Fig 1: Turn Signal/Multi-Function Switch C4 Connector End View
Courtesy of ISUZU MOTOR CO.
Courtesy of ISUZU MOTOR CO.
