DTC P0730: Gear Error Without Input Speed
›
Notes
DTC P0730: Gear Error Without Input Speed: Notes
Fig 1: DTC P0730 Gear Error Without Input Speed (Sectional View Of Automatic Transmission)
Courtesy of ISUZU MOTOR CO.
