Illustration Arrows

Arrows are designed for specific purposes to aid your understanding of technical illustrations.

Fig 1: Illustration Arrows Description Chart (1 Of 2)

Courtesy of ISUZU MOTOR CO.

Fig 2: Illustration Arrows Description Chart (2 Of 2)

Courtesy of ISUZU MOTOR CO.
