Starters - LUCAS: Overhaul: Reassembly
- Be sure that all parts are clean. Reverse disassembly procedure, using a new lock ring and spire nut. Lightly lubricate bearing surfaces and pivot pin.
- Armature end play should be adjusted to maximum end play of 0.010" (0.25 mm) by driving retaining ring (spire nut) to proper position.
