Component Locations
NOTE:
For view of transmission component locations, see Figure
.
COMPONENT LOCATIONS
| Component | Location | |
|---|---|---|
| ACC Switch | Left Front Of Engine Compartment | |
| BPP Switch | On Top Of Brake Support | |
| Intake Air Temperature Sensor | On Left Side Of Engine Compartment | |
| Mass Airflow Sensor | On Air Intake Assembly | |
| PCM | ||
| Ford Thunderbird | At Right Strut Tower | |
| Jaguar S-Type & Lincoln LS | Right Rear Of Engine Compartment | |
| TP Sensor | On Right Side Of Engine | |
