Compass Mini/Trip Computer: Removal

Remove overhead console, refer to REMOVAL .
Remove mounting screws and release the map lamp wire connector from the compass mini-trip computer. (Fig 1 ).

Fig 1: Locating Compass Mini-Trip Computer Retaining Screws
Courtesy of DAIMLERCHRYSLER CORP.
Remove the compass mini-trip computer from the overhead console.
