CLOCKSPRING C1 Connector End View
CLOCKSPRING C1 Connector End View
Fig 1: Clockspring Connector End View (C6)
Courtesy of DAIMLERCHRYSLER CORP.
Courtesy of DAIMLERCHRYSLER CORP.
