Connector End Views & Electrical Component Locations: S352
Harness-Family: Liftgate
Color: NA
Gender: FEMALE
Part Number: NA
Part Description: Not Available
Connector No: S1801
Option: Standard
Repair Kit Part Number: Not Available
Cavity Count:
| Pin | Circuit | Wire Color | Gauge/Size | Function | Option | ||
|---|---|---|---|---|---|---|---|
| 1 | G80 | VT/BR | 20 | FLIP-UP GLASS AJAR SWITCH SENSE | N/A | ||
| 2 | G80 | VT/BR | 20 | FLIP-UP GLASS AJAR SWITCH SENSE | N/A | ||
| 3 | G80 | VT/BR | 20 | FLIP-UP GLASS AJAR SWITCH SENSE | N/A | ||
|
|||||||
