Connector End Views & Electrical Component Locations: S325

Harness-Family: Body

Color: NA

Gender: FEMALE

Part Number: NA

Part Description: Not Available

Connector No: S125

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count:

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	A931	RD/WT	22	FUSED B(+)	N/A
2	A931	RD/WT	22	FUSED B(+)	N/A
3	A931	RD/WT	22	FUSED B(+)	N/A
4	A931	RD/WT	22	FUSED B(+)	N/A
5	A931	RD/WT	22	FUSED B(+)	N/A
(1) Pins not listed are not used for this connector
