Connector End Views & Electrical Component Locations: S139
Harness-Family: Engine
Color: NA
Gender: FEMALE
Part Number: NA
Part Description: Not Available
Connector No: S906
Option: Standard
Repair Kit Part Number: Not Available
Cavity Count:
| Pin | Circuit | Wire Color | Gauge/Size | Function | Option | ||
|---|---|---|---|---|---|---|---|
| 1 | F855 | PK/YL | 20 | 5 VOLT SUPPLY | N/A | ||
| 2 | F855 | PK/YL | 20 | 5 VOLT SUPPLY | N/A | ||
| 3 | F855 | PK/YL | 18 | 5 VOLT SUPPLY | N/A | ||
| 4 | F855 | PK/YL | 20 | 5 VOLT SUPPLY | N/A | ||
| 5 | F855 | PK/YL | 20 | 5 VOLT SUPPLY | N/A | ||
|
|||||||
