RELAY, Auto Shut Down: Installation: Installation
Fig 1: Identifying Power Distribution Center (PDC) & Left Inner Fender
Courtesy of CHRYSLER LLC
Refer to TIPM cover for ASD relay location.
Install relay to TIPM (1).
Install cover to TIPM.
