Regulator, Fuel Pressure: Installation: Installation
Courtesy of CHRYSLER GROUP, LLC
- Install the fuel rail pressure sensor (2) onto fuel rail (3). Tighten to 35 N.m (26 ft. lbs.).
- Connect the fuel rail pressure sensor harness connector (1).
- Connect the negative battery cable.
