Installation 2.2L

Fig 1: Right Side Charge Air Cooler (CAC) Temperature Sensor Wire Harness Connector
GC0170021Courtesy of CHRYSLER GROUP, LLC
  1. Install the inlet air temperature sensor (2) into the Charge Air Cooler (CAC) inlet tube. Tighten the sensor to proper SPECIFICATIONS  .
  2. Connect the inlet air temperature sensor wire harness connector (1).
  3. Install the right front wheelhouse splash shield. Refer to SHIELD, SPLASH, FRONT WHEELHOUSE, INSTALLATION .
  4. Connect the negative battery cable. If equipped with an Intelligent Battery Sensor (IBS), connect the IBS connector to the negative battery cable.
