Sensor, Coolant Temperature: Installation: 2.8L

Courtesy of CHRYSLER GROUP, LLC

1. Install coolant temperature sensor (4) in thermostat housing (1) and tighten to 11 N.m (8 ft. lbs.).

   Courtesy of CHRYSLER GROUP, LLC

2. Install the thermostat housing (2). Refer to THERMOSTAT, INSTALLATION .
