Mode 6 - 1996-2017 KIA
›
Mode $06 Data Definitions For 2006-2011 RIO 1.6GDI
Mode $06 Data Definitions For 2006-2011 RIO 1.6GDI
Fig 1: 2006-2011 Rio 1.6GDI
Courtesy of KIA MOTORS AMERICA, INC.
Courtesy of KIA MOTORS AMERICA, INC.
