Upper Arm: Components
Courtesy of KIA MOTORS AMERICA, INC. LEGEND FOR EXPLODED VIEW OF UPPER ARM
| No. |
Component |
| 1 |
Upper Fork |
| 2 |
Front Shock Absorber Assembly |
| 3 |
Fork |
| 4 |
Stabilizer Link |
| 5 |
Stabilizer Bar |
| 6 |
Drive Shaft |
| 7 |
Lower Arm |
| 8 |
Lower Arm Connector |
| 9 |
Bushing (G) |
| 10 |
Bushing (A) |
