Scuff Plate Light: Components

WARNING: This page is about a different car, the 2006 Lexus IS 350 and 2006 Lexus IS 250. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Identifying Scuff Plate Light Components

Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.
