Pressure Control Solenoid Valve (PCSV)
›
Description
›
Features
Pressure Control Solenoid Valve (PCSV): Description: Features
Fig 1: Automatic Transaxle Control System Features
Courtesy of KIA MOTORS AMERICA, INC.
Courtesy of KIA MOTORS AMERICA, INC.
