P1675: Transponder Programming Error
›
Diagnostic Circuit Diagram
Diagnostic Circuit Diagram
Fig 1: Instrument Cluster - Circuit Diagram
Courtesy of KIA MOTORS AMERICA, INC.
Courtesy of KIA MOTORS AMERICA, INC.
