Circuit Diagram

Fig 1: Body Control Module (BCM) - Circuit Diagram (1 Of 2)

Courtesy of KIA MOTORS AMERICA, INC.

Fig 2: Body Control Module (BCM) - Circuit Diagram (2 Of 2)

Courtesy of KIA MOTORS AMERICA, INC.
