Audio Assembly Replacement

Remove the center fascia panel.
Remove the mounting screws (4 EA) then remove the audio unit (A).

Fig 1: Audio Assembly & Mounting Screws
Courtesy of KIA MOTORS AMERICA, INC.
Disconnect the connectors (A).
Installation is the reverse of removal.
