Repair procedures: Removal
- Remove the negative (-) battery terminal.
- Remove the crash pad lower panel. (Refer to "CRASH PAD " in BD group.)
- Remove the oil pump unit connector to the left side of the brake pedal.
- Remove the oil pump unit (A) after removing the nuts (3ea).
