Component Location

WARNING: This page is about a different car, the 2015 Kia Soul EV. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Lost Communication With Telematic Control Module

Courtesy of KIA MOTORS AMERICA, INC.

* Electric Power Control Unit - EPCU(VCU+MCU+LDC)

Vehicle Control Unit (VCU)
Motor Control Unit (MCU)
Low DC-DC Converter (LDC)
