Kia
›
2016
›
Soul Base, Automatic Trans
›
Repair and Diagnosis
›
Drivelines & Axles
›
Axle Shafts
›
Driveshaft Assembly
›
TJ Joint
›
Components And Components Location
›
Components
›
RH
Components And Components Location: Components: RH
Fig 1: TJ Joint Exploded View RH
Courtesy of KIA MOTORS AMERICA, INC.
Courtesy of KIA MOTORS AMERICA, INC.
