Timing System - 1.6L
›
Timing Chain Cover
›
Components And Components Location
›
Components
Components And Components Location: Components
Fig 1: Timing Chain Cover With Torque Specifications
Courtesy of KIA MOTORS AMERICA, INC.
Courtesy of KIA MOTORS AMERICA, INC.
