Chart 2

WARNING: This page is about a different car, the 2018 Kia Forte5 and 2018 Kia Forte. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Multi-Media Jack Troubleshooting Flow Chart 2

Courtesy of KIA MOTORS AMERICA, INC.
