Repair Procedures: Installation

1. Install in the reverse order of removal.

NOTE: Perform the clutch touch point learning procedure using the KDS/GDS after replacing TCM.

Fig 1: Screen Display - Perform Clutch Touch Point Learning Procedure

Courtesy of KIA MOTORS AMERICA, INC.
