Repair Procedures: Removal
WARNING: This page is about a different car, the 2018 Hyundai Ioniq. However, it is still accessible from the selected car via links, so may be relevant.
- Disconnect the negative (-) battery terminal.
- Remove the glove box.
(Refer to "GLOVE BOX UPPER COVER ASSEMBLY ")
- Detach the body control module (A) after loosening the bolts (B) and nut (C).
- Remove the body control module (A) after disconnecting the connectors (B).
