Repair Procedures: Removal
WARNING: This page is about a different car, the 2021 Kia Seltos. However, it is still accessible from the selected car via links, so may be relevant.
- Disconnect the negative battery terminal.
- Remove the engine room under cover.
G 1.6 T-GDI (Refer to Engine Mechanical System - "ENGINE ROOM UNDER COVER ")
G 2.0 Nu MPI (Refer to Engine Mechanical System - "ENGINE ROOM UNDER COVER ")
- Remove the front wheel guard.
(Refer to Body - "FRONT WHEEL GUARD ")
- Disconnect the front fog lamp connector (A).
- Remove the front fog lamp assembly (B) after loosening the mounting screws.
