| 1 |
Rear door left speaker (+) |
- |
- |
- |
Ground |
| 2 |
Rear door left speaker (-) |
- |
MIC (+) |
- |
- |
| 3 |
- |
Amplifier navigation voice (+) |
- |
- |
Hazard switch |
| 4 |
- |
Amplifier_SPDIF (High) |
- |
- |
Passenger seat belt reminder |
| 5 |
- |
Antenna power |
- |
- |
| 6 |
RVM Camera: Power |
Illumination (+) |
- |
Telltale/PAB Off |
| SVM Camera: - |
| 7 |
RVM Camera: Video |
Multimedia-CAN (High) |
- |
IGN1 |
| SVM Camera: Video (Y) |
| 8 |
RVM Camera: - |
Monitor board_enable |
- |
PAB On |
| SVM Camera: Video (C) |
| 9 |
- |
- |
- |
- |
| 10 |
AUX Audio right_input |
Battery (+) |
- |
- |
| 11 |
AUX_Detect |
Battery (+) |
- |
- |
| 12 |
Steering wheel key |
Ground |
- |
Hazard lamp |
| 13 |
Front door left speaker (+) |
- |
Ground |
- |
|
| 14 |
Front door left speaker (-) |
- |
MIC Ground |
- |
| 15 |
Front door right speaker (-) |
- |
MIC (-) |
- |
|
| 16 |
Front door right speaker (+) |
- |
RVM Camera: - |
- |
| SVM Camera: Equipment_Detect |
- |
| 17 |
- |
Amplifier navigation voice (-) |
- |
- |
| 18 |
- |
Amplifier SPDIF (Low) |
- |
- |
| 19 |
- |
Amplifier SPDIF (Ground) |
Illumination (-) |
- |
| 20 |
RVM Camera: Power ground |
Multimedia-CAN (Low) |
- |
| SVM Camera: - |
- |
| 21 |
RVM Camera: Video ground |
Display_Mute |
- |
| SVM Camera: Video (Y) ground |
| 22 |
RVM Camera: - |
ACC |
|
| SVM Camera: Video (C) ground |
| 23 |
- |
- |
| 24 |
AUX Audio left_input |
LCD Battery |
| 25 |
AUX Audio ground |
- |
| 26 |
Steering wheel remote controller (Ground) |
- |
| 27 |
Rear door right speaker (-) |
- |
- |
| 28 |
Rear door right speaker (+) |
- |
- |
| 29 |
- |
- |
| 30 |
- |
- |
| 31 |
- |
- |
| 32 |
RVM Camera: - |
- |
| SVM Camera: Equipment_Detect |
- |
| 33 |
RVM Camera: - |
IGN1 |
| SVM Camera: Video (Y) shield |
| 34 |
RVM Camera: - |
- |
| SVM Camera: Video (C) shield |
| 35 |
- |
LCD Ground |
| 36 |
- |
|
| 37 |
- |
| 38 |
Vehicle Speed |
