Rail Pressure Sensor (RPS): Specifications

Courtesy of KIA MOTORS AMERICA, INC.

Item	Specification
Rated Voltage (V)	5
Operating Voltage (V)	4.75 - 5.25
Operating Temperature [°C (°F)]	-40 to 150 (-40 to 320)
Operating Pressure (bar)	0 - 450

Item		Specification
Pressure	bar	0	225	450
	Mpa	0	22.5	45
	kgf/cm2	0	229.4	458.8
Output Voltage (V)	25°C (77°F)	0.5 ± 0.40	2.5 ± 0.56	4.5 ± 0.72
	-40°C (-40°F)	0.5 ± 0.06	2.5 ± 0.84	4.5 ± 0.108
	140°C (284°F)
