Shift Cable: Adjust

Position vehicle on ramp. See JACKING & HOISTING .
Select position Park.
Loosen selector cable trunnion nut. See Fig 1.
Ensure that gearbox selector lever is in Park position, (fully forward) and tighten trunnion nut.
Lower ramp.

Fig 1: Adjusting Shift Cable

Courtesy of LAND ROVER NORTH AMERICA, INC.
