Image Processing Module (IPM)

WARNING: This page is about a different car, the 2018 Jaguar XF, 2017 Jaguar XF, and 2016 Jaguar XF. However, it is still accessible from the selected car via links, so may be relevant.

The Image Processing Module (IPM) is able to detect road lane markings, traffic sign markings and monitor the road ahead for Lane Departure Warning (LDW), Lane Keep Assist (LKA), Traffic Sign Recognition (TSR) and Autonomous Emergency Braking (AEB) systems.

The IPM also hosts the software for:

Driver Drowsiness Detection (DDD) system.
Intelligent Speed Limiter (ISL) system.

For additional information, refer to: Speed Control .

The IPM is located in the rear view mirror.

The IPM is a module that has two built in forward facing cameras. The IPM receives an ignition supply from the Rear Junction Box (RJB) and information can be exchanged from the IPM via the High Speed (HS) Controller Area Network (CAN) chassis bus to the other modules.
