Trouble No. 2: Shift Point Too Hi Or Too Lo
Trouble No. 2: Shift Point Too Hi Or Too Lo
Fig 1: Trouble No. 2: Shift Point Too High or Too Lo
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
