Window Regulator (Rear): Installation

1. Install window regulator. Install the regulator with 4 bolts. See Fig 1.
2. Connect the connector and install it to the panel.

Fig 1: Installing Rear Window Regulator

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
