Starter Motor: Installation

1. To install, reverse removal procedure. See TORQUE SPECIFICATIONS table. Ensure White mark on intake manifold gasket faces upward. DO NOT touch air intake chamber and adapter gasket surfaces with hands.
2. DO NOT touch EGR pipe and air intake plenum gasket surfaces with hands. Apply Seal Packing (08826-00100 ) around rectangular opening of thermostat housing. Add coolant to engine and check oil level. Start engine and check for coolant, oil and fuel leaks. Check ignition timing and road test vehicle.

Fig 1: Removing & Installing Starter

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
