Code 27 - Sub-Oxygen Sensor Circuit (Left Bank)
Code 27 - Sub-Oxygen Sensor Circuit (Left Bank)
Fig 1: Code 27 Flow Chart (LS400) Sub-Oxygen Sensor Circuit (Left Bank)
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
