How To Proceed With Troubleshooting

HINT:

The ECU is connected to the multiplex communication system. Therefore, be sure to check that there is no troubles in the multiplex communication system before performing the troubleshooting.

Fig 1: Drive Side Junction Block (Body No. 2) Control System Troubleshooting Flow Chart
