Sliding Roof System
HINT:
The sliding roof system must be initialized after any of the following is done:
- The battery is disconnected.
- The S/ROOF fuse is replaced.
- The sliding roof assembly (sliding roof ECU) is replaced.
- The sliding roof is removed and reinstalled or replaced.
Initialize the sliding roof system as follows:
- Using the tilt switch, tilt the roof fully upward, and then fully downward.
- Using the slide switch, fully open the roof, and then fully close it.
