Oil Pump Assembly: Installation

INSTALL OIL PUMP ASSEMBLY
1. Install the oil pump assembly with the 2 nuts.
  Torque: 7.0 N*m (71 kgf*cm, 62 in.*lbf)
2. Connect the 2 oil cooler hoses.
3. Connect the oil cooler connector.

  Fig 1: Installing Oil Pump Assembly
  Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
INSTALL FRONT BUMPER ASSEMBLY
(See INSTALLATION )
ADD AND INSPECT HYBRID TRANSAXLE FLUID
(See HYBRID TRANSAXLE FLUID )
