Shift Solenoid Valve: Components

Fig 1: Exploded View Of Shift Solenoid Valve With Torque Specifications (1 Of 2)

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

Fig 2: Exploded View Of Shift Solenoid Valve With Torque Specifications(2 Of 2)

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
