Home › Lexus › 2007 › LS 460L › Repair and Diagnosis › Heating, Ventilation & A/C (HVAC) › HVAC Control Systems › Air Conditioning › Rear Evaporator Temperature Sensor › Components

Rear Evaporator Temperature Sensor: Components

Fig 1: Rear Evaporator Temperature Sensor Replacement Components With Torque Specifications
G04950806Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
