DTC C1244/44 Open or Short in Deceleration Sensor Circuit: Wiring Diagram
Fig 1: Open Or Short In Deceleration Sensor - Wiring Diagram
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
