License Plate Light Assembly: Disassembly

WARNING: This page is about a different car, the 2006 Lexus RX 400h. However, it is still accessible from the selected car via links, so may be relevant.
  1. REMOVE LICENSE PLATE LIGHT BULB
    1. Turn in the direction indicated by the arrow and remove the license plate light bulb and the license plate light socket as a unit.
    2. Remove the license plate light bulb from the license plate light socket.
      Fig 1: Identifying License Plate Light Bulb
      G04115125Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
