Fuel Injector (For Direct Injection), Intake Manifold: Components

Fig 1: Fuel Injector Replacement Components With Torque Specifications - For Direct Injection (1 Of 5)

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

Fig 2: Fuel Injector Replacement Components With Torque Specifications - For Direct Injection (2 Of 5)

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

Fig 3: Fuel Injector Replacement Components With Torque Specifications - For Direct Injection (3 Of 5)

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

Fig 4: Fuel Injector Replacement Components With Torque Specifications - For Direct Injection (4 Of 5)

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

Fig 5: Fuel Injector Replacement Components With Torque Specifications - For Direct Injection (5 Of 5)

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
