DAMPING FORCE CONTROL ACTUATOR (for Rear Side): Components

Fig 1: Identifying Damping Force Control Actuator [For Rear Side] Replacement Components With Torque Specifications (1 Of 2)

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

Fig 2: Identifying Damping Force Control Actuator [For Rear Side] Replacement Components With Torque Specifications (2 Of 2)

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
