Lexus
›
2008
›
RX 350 AWD
›
Repair and Diagnosis
›
Engine Mechanical
›
Lubrication System
›
Lubrication
›
Oil Pump
›
Components
Oil Pump: Components
Fig 1: Identifying Oil Pump Replacement Components With Torque Specification (1 Of 4)
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Fig 2: Identifying Oil Pump Replacement Components With Torque Specification (2 Of 4)
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Fig 3: Identifying Oil Pump Replacement Components With Torque Specifications (3 Of 4)
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Fig 4: Identifying Oil Pump Replacement Components With Torque Specifications (4 Of 4)
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
